1.
kW / PF
Active Power, Power Factor Measurement Button
Press
kW / PF
button to measure Active Power and Power Factor in
measurement mode. Then the LCD shows Active Power reading in
the primary display and Power Factor reading in the secondary
display.
2.
kVAr
kVA
Apparent power, Reactive Power measurement button
Press
kVAr
kVA
button to measure Apparent Power and Reactive
Power in measurement mode. Then the LCD shows Apparent Power
reading in the primary display and Reactive Power reading in the
secondary display.
3．
kWh
TIME
Active Energy, Time Measurement Button
Press
kWh
TIME
button to measure Active Energy in measurement
mode. Then the LCD shows Active Energy reading in the primary
display and measurement time of the Active Energy in the secondary
display.
4． Power Summation Button
Press button to sum up the measured value of current one
phase in three phase measurement mode; then measure the second
phase and press the button to sum up again; press the
button for the third phase after you getting the measured
value of the third phase on the display. So the meter will calculate the
sum in this three phase system automatically, you will rotate the
selector to ∑W at one time, then the display shows the total power
value.
5． oltage Measurement Button V
Press button to measure voltage of the circuit and display
the measured value in the LCD display.
– 7 –
V / Hz
V / Hz
