NTP Driven Clocks
NTDS16
MASTERCLOCK, INC. 5-YEAR LIMITED PARTS & LABOR WARRANTY MADE IN THE USA
phone (USA and Canada): phone (international): email: online:
1-800-940-2248 +1-636-724-3666 sales@masterclock.com www.masterclock.com
GMR Series Options
High Stability Oscillators
Freq. = 10 MHz
HSO-1 HSO-2 HSO-3
Oscillator Type TCXO OXCO Rubidium
Freq. Stability - Aging/Day
≤ ± 0.0027ppm
(or 2.7E-9/day)
≤ ±1E-9/day ±4E-11/day
Freq. Stability - Aging/Year
≤ ± 1.0 ppm
(or 1E-6 /year)
≤ ±1E-7/year ±1.5E-9/year
Power Consumption ≤0.021W
≤3.5W warm up,
≤1.5W steady state
≤14W warm up,
≤ 8 W steady state
ROHS Compliant Yes Yes Yes
Short Term Stability
(Allan Variance), t =1sec.
- - ≤5E-11
Time Drift per Year (max) ± 3 sec./year ± 0.25 sec./year ± .001 sec. / year
Phase Noise
(dBc/Hz) @ 10
MHz
1 Hz - - ≤-65 dBc/Hz
10 Hz - ≤-110 dBc/Hz ≤-85 dBc/Hz
100 Hz ≤-135 dBc/Hz ≤-130 dBc/Hz ≤-112 dBc/Hz
1k Hz ≤-135 dBc/Hz ≤-145 dBc/Hz ≤-130 dBc/Hz
10k Hz ≤-148 dBc/Hz ≤-155 dBc/Hz ≤-140 dBc/Hz
Available only in GMR5000
Standard
Masterclock oers three high-stability oscillator options for the GMR Series. When locked to GPS, the OCXO 10 MHz sine wave frequency
will have the same long-term stability as an atomic clock. When not tied to GPS, a precision frequency 10 MHz reference output is
available as a source for laboratory use or for an RF reference, including cellular applications. The HSO option is required for all
10 MHz signal outputs.
