Boat Operations • 2014 MasterCraft Owners Manual Page 4-33
B O A T O P E R A T I O N S
MENTS, USE SHORT MOMENTARY
TAPS OF THE SWITCH.
Special Attention:
On the X2, X10 and X25 models, at-
titude adjustment plates are limited to
fty percent (50%) maximum extension
when the boat speed exceeds twenty
miles per hour (20 mph) or thirty-two
kilometers per hour (32 km/h).
Maneuvering a boat with the atti-
tude adjustment plate extended requires
practice to master. Initial times run-
ning with the attitude adjustment plate
extended should be done at low speed
with plenty of room. This is critical to
learning how the attitude adjustment
plate affects control and maneuverabil-
ity, especially when teaming the attitude
adjustment plate with surf tabs.
Additional Special Attention:
DO NOT use the attitude adjustment
plate(s) to board the boat. The edges are
sharp and can easily slice through skin.
The plate(s) is also not sturdy enough to
withstand many people’s body weight.
Damage to the plate(s) in this manner
is not covered under warranty. Use only
boarding ladders and swim platforms to
board from the transom side when boats
are equipped with an attitude adjustment
plate(s).
Never use the attitude adjustment plate(s)
to board or assist in boarding the boat.
Sharp edges can cut individuals, causing
potentially serious bleeding. Damage to
the plate(s) from people using it to board
the boat is not covered under warranty.
Additional Special Attention:
Care should also be taken when
backing up the boat in shallow water, re-
moving boats from the water on steeply
pitched access areas, or backing up with
the boat on a trailer. The attitude adjust-
ment plate(s) does not fold or retract,
and it may require additional clearance
to avoid damage to the plate(s). Result-
ing damage from failure to follow in-
structions is not covered under warranty.
Care must be taken to ensure that there is
always sucient clearance around the at-
titude adjustment plate, whether it is in the
water or out, particularly on a trailer. The
attitude adjustment plate(s) extends be-
yond the boat transom and is not foldable
or retractable. Damage to the plate(s) from
failure to allow sucient clearance is not
covered under warranty.
Troubleshooting:
1) If the switch(es) is/are unresponsive,
check the main circuit break panel to de-
termine if the circuit has tripped. Re-set
the circuit and try the switch again.
2) If the circuit continues to trip, present
the boat to an authorized MasterCraft
dealer for repair.
3) If the boat does not respond as noted
in the above instructions, turn OFF the
switch and do not use the attitude ad-
justment function until the system has
been checked by authorized MasterCraft
To Next Page
