Ballast Settings Page
This screen provides the ability to con-
trol the ballast ll and drain times.
To adjust the ll and drain times use the
soft keys. Use the [NEXT SETTING] key
to move between the times. Use the UP and
DOWN arrow keys to adjust the minutes
and seconds.
Paddle Wheel Offset
Sets the paddle wheel offset.
Service Information
This set of screens provides the ability
for the user to view the software versions.
In addition, it allows the dealer to reset the
oil change and the dealer service schedule.
NOTE: The Dealer Service Reset re-
quires a dealer code to be entered before
gaining access to the screens.
Software Version
This screen is an information-only
screen that provides the following:
• Application version and part number
• Operating system version and
part number
• Bootloader version and part number
• Software version
Dealer Service Reset
This is a dealer-only screen that provides
the dealer with a method to reset the engine
hours for service. Engines are required to
have service every 100 hours of operation.
When the 100 engine hours are reached, an
alert is displayed to alert the boat owner/
operator to perform the necessary mainte-
nance.
Oil Change Reset
This is a dealer-only screen that pro-
vides the dealer with a method to reset the
engine hours for service. An Oil Change
alert is displayed the rst time after ten (10)
engine hours. Subsequent alerts are dis-
played at fty (50) engine hour intervals.
Gauges & Video Screens • 2014 MasterCraft Owners Manual Page 3-13
G A U G E S & V I D E O S C R E E N S
