X55
Page 2-16 2014 MasterCraft Owners Manual • Guide to Individual Models
G U I D E T O I N D I V I D U A L M O D E L S
Length of Boat .........................25’5”
Width Amidship .........................102”
Boat Weight ....... 4,850-5,000 lbs.
Length of Boat w/Platform .. 27’8”
Towing Length .......................... 31’2”
Towing Width .............................102”
Fuel Capacity ................. 90 gallons
Maximum Capacity .........................
................18 people or 3,065 lbs.
................ Bow: 5 people or 700 lbs.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, and port and starboard sun pads.
1 = Anchor storage
2 = Ladder (where equipped)
3 = Bow cleat
4 = Horn
5 = Ballast tank (beneath oorboard)
6 = Amp
7 = Holding tank pump-out
8 = Circuit breaker panel (on kick panel beneath
instrument panel)
9 = Adjustable mirror
10 = Nav/anchor light
11 = Instrument panel (details in Video Display
Gauge section)
12 = Steering wheel
13 = Shift/throttle control
14 = Midship cleat
15 = Fire suppression unit manual override
16 = Heated seat (where equipped)
17 = Wet bar and shower (where equipped)
18 = Upright refrigerator (under sink, where
equipped)
19 = Engine compartment
20 = Fuel tank ller
21 = Automatic re extinguisher
22 = Engine compartment exhaust (two, on top of
port and starboard near transom)
23 = Stern cleat
24 = Stern light receptacle (if equipped with tower,
light will be in center aft of tower)
25 = Freshwater ush port (where equipped)
26 = Underwater lights (two, where equipped,
under swim platform)
27 = Transom drain plug (center beneath swim
platform)
28 = Transom rail with tow eye
29 = Swim platform
30 = Wake adjustment plate (under swim
platform, where equipped)
31 = Surf tabs (under swim platform, where
equipped)
32 = Freshwater tank ll
33 = Stern cleat
34 = Engine compartment exhaust (two, on top of
port and starboard deck near transom)
35 = Fuel tank ller
36 = Ski pylon
37 = Batteries ON-OFF switch (under seat)
38 = Cooler (under seat)
39 = Washdown connection
40 = Batteries (under seat)
41 = Subwoofer
42 = Convertible observer seat
43 = Midship cleat
44 = Center drain plug (access plate under carpet mat)
45 = Glove box
46 = Nav/anchor light
47 = Amp (below)
48 = Stereo remote (on dash)
49 = iPod interface (inside head, where equipped)
50 = Hand-held re extinguisher (inside head)
51 = Head
52 = Amp (where equipped)
53 = Bow ller cushion (where equipped)
54 = Bow cleat
