Page 2-2 2014 MasterCraft Owners Manual • Guide to Individual Models
G U I D E T O I N D I V I D U A L M O D E L S
14v/X14v
Length of Boat ..........................21’4”
Width Amidship ..........................96”
Boat Weight ............3,400 lbs. est.
Length of Boat w/Platform . 23’8”
Towing Length ......................... 24’4”
Towing Width ............................ 100”
Fuel Capacity ................. 34 gallons
Maximum Capacity .........................
.................11 people or 1,307 lbs.;
................Bow: 3 people or 450 lbs.
Storage space is located under:
Observer’s seat, bow seating, aft seating, and
port side seating.
1 = Bow light
2 = Bilge thru-hull outlet
3 = Ballast thru-hull vent
4 = Bow cleat
5 = Adjustable mirror
6 = Stereo remote (on dash)
7 = Amp (below)
8 = Circuit breaker panel (on kick panel beneath
instrument panel)
9 = Instrument panel (details under Video
Display Gauge section)
10 = Steering wheel
11 = Shift/throttle control
12 = Subwoofer (where equipped)
13 = Fire suppression unit manual override
14 = Cooler (located under seat)
15 = Engine compartment
16 = Ballast thru-hull pump-out
17 = Fuel tank ller
18 = Stern cleat
19 = Auto re extinguisher
20 = Stern light receptacle (if equipped with
tower, the light will be in center
aft of tower)
21 = Shower wand & switch (where equipped,
inside storage compartment)
22 = Blower exhaust (top of deck near transom)
23 = Transom stereo remote (where equipped)
24 = Aft ski pylon
25 = Transom rail with tow eye
26 = Transom drain plug (center beneath
swim platform)
27 = Underwater lights (two where equipped
under swim platform)
28 = Swim platform
29 = Stern cleat
30 = Fuel tank ller
31 = Ballast thru-hull vent
32 = Ski pylon
33 = Center drain plug (under inspection plate)
34 = Convertible jump seat (where equipped) or
walk-thru seat (where equipped)
35 = iPod interface (where equipped)
36 = Amp (where equipped, beneath observer seat)
37 = Hand-held re extinguishers (beneath
observer seat)
38 = MTS Ballast System (where equipped,
beneath observer seat)
39 = Battery (in void beneath observer seat)
40 = Glove box
41 = Bow cleat
42 = Bow ller cushion (where equipped)
