This screen shows the ballast tank ll
and empty activity. In addition, it shows
the attitude adjustment (trim) and surf tab
levels. The only soft key on this screen is
the Autolaunch/Exit key. Press this key to
turn Autolaunch/Exit ON and OFF.
Gauges
The Gauges screen is accessible
by pressing the Quick Access Key.
This screen shows the speedom-
eter, air temperature, water temperature,
battery voltage, water depth and engine
hours information.
NOTE: This screen is display-only.
There are no soft keys for this screen.
Cruise/Profile
The Proles screen can be ac-
cessed by pressing Quick Access
Key.
This feature displays rider/user proles
for cruise controls based on user preferences
for speed, ballast and smartplate settings.
Cruise/Prole Screen—
Soft Key Commands
PROFILES—use this key to access
a list of preloaded proles. Use the UP
ARROW or DOWN ARROW to scroll
through the list. Press [SELECT PRO-
FILE] to select the outlined prole.
CRUISE—Use this key to turn the Cruise
Control ON or OFF.
UP ARROW—Use this key to increase the
set speed.
DOWN ARROW—Use this key to de-
crease the set speed.
AUTOLAUNCH/EXIT—Press and hold
the Menu key to turn Autolaunch ON or
OFF. When Autolaunch is ON, it automati-
cally controls the center tab. When speed is
above the Autolaunch speed, the center tab
will be retracted to zero percent (0%). Or if
a prole is selected, it deploys the center tab
to the prole setting. If the speed is above
the Autolaunch speed and then decelerated
Page 3-10 2014 MasterCraft Owners Manual • Gauges & Video Screens
G A U G E S & V I D E O S C R E E N S
