3-30 MASTERFLEX
®
Digital Pump Drive Operating Manual Masterflex
Section 3
Operation
Autostart Menu
(continued)
The following table shows the drives function when Autostart is used in
combination with the Start/Stop input.
Table 3-2. Continuous Mode Operation.
MENU SETTINGS INTERNAL MODE mA or V MODE
AUTO START/STOP Drive State When Drive Response When Drive Running
START INPUT Powered OFF Powered ON (sufficient level)
When Powered OFF
Drive Response when
Powered ON
(sufficient level present)
OFF OPEN Started from Front panel Not running Not running
Running
OFF OPEN Not running Not running Not running
OFF CLOSED Running Not running Not running
OFF CLOSED Stopped from Front panel Not running Not running
ON OPEN Started from Front panel Running Running
Running
ON OPEN Not running Not running Not running
ON CLOSED Running Running Running
ON CLOSED Stopped from Front panel Not running Not running
Not running
NOTE: In Continuous Mode when using the START/STOP input the drive is started with a closed contact and
stopped when the contacts are opened.
