MASTERFLEX
®
Digital Pump Drive Operating Manual 3-35Masterflex
Section 3
Operation
Figure 3-19. Set Copy Menu Screens.
PREPARING TUBING: Insert the tube inlet into the supply fluid. Next,
insert the tube outlet into desired container.
FLOW DIRECTION : Pressing the ENTER key with this icon
highlighted, toggles between clockwise and counterclockwise flow
direction.
SET COPY: Press the START/RUN key on the control panel to
initiate copy. Once the amount of desired fluid is dispensed, press the
STOP/PAUSE key .
SAVE COPY : Pressing the ENTER key with this icon highlighted will
save the copy.
Set Copy Menu
