12
CombiMaster 120V Series
–
Us
er
and
I
nstallation Manual
4.3
Batteries
Model
Recommended battery capacit
y
Minimum
,
based on Mastervolt Gel
batteries. If connecting batteries of a
different manufact
urer, make sure
the manufacturer's rec
ommendations
are met.
12V/1500W
-
60A
120
−
600 Ah
12V/2000W
-
100A
200
−
1000 Ah
12V/3000W
-
160A
320
−
1600 Ah
12V/3500W
-
200A
400
−
2000 Ah
24V/2000W
-
60A
120
−
600 Ah
24V/3000W
-
70A
140
−
700 Ah
24V/3500W
-
100A
200
−
1000 Ah
24V/4500W
-
120A
-
HT
240
−
1200 Ah
48V/5000W
-
70A
-
HT
140
−
700 Ah
11
13
