CombiMaster 120V Series –
User and Installation Manual
31
5.2.5 Events tab – System automation
A MasterBus device can be programmed to initiate an action at another connected device. This is very
helpful in automation of your system but is not required. In MasterBus this is done by means of event-
based commands. In the Events tab you can program the CombiMaster Inverter/Charger to act as an
event source. Events which occur during the operation of the CombiMaster Inverter/Charger will then
trigger actions from other products. The following parameters are shown in MasterAdjust.
Field
Meaning
Value
Event x source
Select an event that triggers an action, e.g. Battery pre low.
See Event source list
Event x target
Select the device that should take action, e.g. the
generator.
System dependent
Event x command
Select the parameter that must be changed on the target
device, e.g. Activate.
See command list of the
selected device
Event x data
Data, e.g. On, is linked to the command.
Off, On, Copy,
Copy Invert, Toggle
Table 1: MasterBus event parameters
The CombiMaster Inverter/Charger can be configured as an event source. An event source can be
used to initiate an event command and an event action by another device that is connected to the
MasterBus.
Event source
Description
Inverting
The CombiMaster Inverter/Charger is in Inverter mode
Charging
The CombiMaster Inverter/Charger is in Charger mode
Supporting
The CombiMaster Inverter/Charger is in Supporting mode
Overload
The loads exceed the nominal inverter power
DC low voltage
The main battery voltage has dropped below the Low bat value
Alarm
A CombiMaster Inverter/Charger alarm has been triggered
AC IN present
AC input is present
Bulk
Charge phase Bulk
Absorption
Charge phase Absorption
Float
Charge phase Float
AC IN Limit A
AC input is set to 6A
AC IN Limit B
AC input is set to 10A
AC IN Limit C
AC input is set to 16A
Table 2: CombiMaster 120V Series MasterBus Event sources
When the CombiMaster Inverter/Charger is configured as an event target by another device, this device
can initiate an event command and an event action to be performed by the CombiMaster
Inverter/Charger.
Event command
Description
Inverter
Change the CombiMaster Inverter/Charger inverter state
Charger
Change the CombiMaster Inverter/Charger charger state
AC limit A
Fuse setting of the AC input is set to 6A (adjustable)
AC limit B
Fuse setting of the AC input is set to 10A (adjustable)
AC limit C
Fuse setting of the AC input is set to 16A (adjustable)
Bulk
Changes to charge phase Bulk
Absorption
Changes to charge phase Absorption
Float
Changes to charge phase Float
Table 3: CombiMaster 120V Series MasterBus Event commands
