Mastervolt CombiMaster 120V Series User Manual

62
CombiMaster 120V Series
– User and Installation Manual
9.7 Dimensions
Model
Product code
h
×
w
×
d in inches [mm]
weight in lb [kg]
CombiMaster 12V/1500W-60A 120V 35511500 14.9 × 11.2 × 6.0
[378 × 284 × 153]
15 [7]
CombiMaster 12V/2000W-100A 120V
CombiMaster 12V/3000W-160A 120V
CombiMaster 24V/2000W-60A 120V
CombiMaster 24V/3000W-70A 120V
35512000
35513000
35522000
35523000
17.6 × 11.2 × 6.0
[448 × 284 × 153]
20 [9]
CombiMaster 12V/3500W-200A 120V
CombiMaster 24V/3500W-100A 120V
CombiMaster 24V/4500W-120A-HT 120V
CombiMaster 48V/5000W-70A-HT 120V
35513500
35523500
35524500
35545000
22.4 × 14.1 × 6.7
[568 × 359 × 170]
37 [17]
Figure 25. Dimensions in inches [mm] of model 1500W
