Mastervolt CombiMaster 120V Series

CombiMaster 120V Series –
User and Installation Manual
27
• Cluster information for a parallel unit in single-phase
Menu
Description
Cluster
Cluster state
the configuration state of the cluster (should be Activated)
Cluster size
the number of CombiMaster Inverter/Charger units in parallel
Cluster L1 IN
Input voltage
Mains input voltage of the cluster
Input current
Mains input current of the cluster
Input frequency
Mains input frequency of the cluster
Cluster L1 OUT
Output voltage
Total AC output voltage of the cluster
Output current
Total AC output current of the cluster
Output frequency
Total AC output frequency of the cluster
Output power
Total AC output power of the cluster
• Cluster information for a unit in split-phase
Menu
Description
Cluster
Cluster state
monitors the configuration state of the cluster
Cluster size
number of CombiMaster Inverter/Charger units in the cluster
Cluster L1 IN
Input voltage
Mains input voltage of the cluster on L1
Input current
Mains input current of the cluster on L1
Input frequency
Mains input frequency of the cluster on L1
Cluster L1 OUT
Output voltage
Total AC output voltage of the cluster on L1
Output current
Total AC output current of the cluster on L1
Output frequency
Total AC output frequency of the cluster on L1
Output power
Total AC output power of the cluster on L1
Cluster L2 IN
Input voltage
Mains input voltage of the cluster on L2
Input current
Mains input current of the cluster on L2
Input frequency
Mains input frequency of the cluster on L2
Cluster L2 OUT
Output voltage
Total AC output voltage of the cluster on L2
Output current
Total AC output current of the cluster on L2
Output frequency
Total AC output frequency of the cluster on L2
Output power
Total AC output power of the cluster on L2
• Cluster information for a parallel unit in split-phase
Menu
Description
Cluster
Cluster state
monitors the configuration state of the cluster
Cluster size
number of CombiMaster Inverter/Charger units in the cluster
Cluster L1 IN
Input voltage
Mains input voltage on L1
Input current
Mains input current on L1
Input frequency
Mains input frequency on L1
