CombiMaster 120V Series –
User and Installation Manual
29
Value Meaning Default Adjustable Range
Device
Language

Menu language of this device
English
English, Nederlands,
Deutsch, Français,
Castellano, Italiano,
Norsk, Svenska,
Suomi, Dansk
Name
Name of this device. This name will be
recognized by all devices connected to the
MasterBus network
CombiMaster
0-12 chars
Model
The CombiMaster Inverter/Charger model
(read only)
Lock config.

Option to lock the configuration (installer
level)
Off
On, Off
Factory reset
button

Button to restore the configuration's default
values
Off
On, Off
CZone enabled
This checkbox is marked when the
CombiMaster Inverter/Charger is setup to
work in a CZone network
Off
(read only)
DIP Switches
1234567890

Position of the DIP switches 0 (read only)
Inverter
Energy save
mode
Option to enable Energy save mode
(only available for standalone unit)
Off
On, Off
Frequency
Inverter frequency
60Hz
50, 60Hz
DC Low on

Voltage level at which the inverter switches
on (DC Low off alarm)
11.5
1)
10.7-12.5
1)
DC Low off
Voltage level at which the inverter switches
off
10.2
1)
10.2-12.0
1)
Charger
Max charge cur.
Maximum charging current
Model-
dependent
0 – model-dependent
Battery type
Select the battery type
Flooded
User defined, AGM,
Gel, Flooded, Li-Ion,
Constant voltage
Constant
voltage
Select the Constant output voltage
13.25V
1)
12-15
1)
Bulk
Voltage
Maximum Bulk voltage
14.25
1)
12-15
1)
Minimum time
Minimum time that the charger stays in
bulk phase
2 min
0-600 min
Maximum time
Maximum time the bulk phase lasts before
the charger transitions to absorption
480 min
0-600 min
Start bulk time
Voltage level at which to start the bulk
timer
13.25
1)
12-15
1)
Absorption
Voltage
Absorption voltage
14.25
1)
12-15
1)
Minimum time
Minimum time that the charger stays in
absorption phase
15 min
0-600 min
Maximum time
Maximum time that the charger stays in
absorption phase
240 min
0-600 min
Return Amps
Return amps (% of maximum charge
current)
6%
0-100%
