Matica MC320 - Rear Bin and Card Feeding Installation

MC320 USER GUIDE
I
3-3
6) Slide Ribbon carrier front side (Leading core) inside the front Guide cores as per instructions till it touches the
bottom of guide core as illustrated below,
7) Close the Top cover.
Note: Ribbon carrier should be assembled without touching/damaging the printer head
3.2 Rear bin Installation
