8.1 mvHYPERION-CLx 29
Note
For Linux there is no CameraLink™ specified library. Therefore we ship CameraLink™ compliant library
libclserMV.so which can be found in the lib directory.
Figure 3: mvHYPERION-CLe
Figure 4: mvHYPERION-CLf
8.1.2.1 Status LEDs
Figure 5: Rev. 1.x
LED Name Description
D9 FPGA state Green: FPGA is loaded
D10 PCI Express® connection state Green: No problem with connection
Figure 6: Rev. 3.x
