Matrix ETERNITY NE Quick Start Guide

2 Matrix ETERNITY NE Quick Start
Ports and Connectors
* To connect SIP Trunks/IP extensions the VoIP module (optional) must be present
in your ETERNITY NE. To connect more than 8 SIP extensions, you must purchase
the IP8 license.
LED
Port Description
24VDC- 2A (Max) Connector for the power adapter.
CO Analog trunk port to connect analog trunk line. RJ11
connector.
DKP Digital Key Phone port to connect
• the proprietary digital key phone of Matrix, EON.
• the PC-based phone EONSOFT.
• the direct station selection console, DSS64 to expand
EON’s key map
SLT Single Line Telephone (SLT) port to connect any standard
analog telephone instrument and fax machine.
Ethernet Ethernet port. Can be used as
• LAN interface to connect a computer/LAN Switch.
• WAN interface* to connect to IP network. As Ethernet
WAN, you can connect a DSL modem/Router or a
LAN Switch.
Door Phone Door Phone port to connect
• a four-wire door phone.
• a door lock release (Relay).
Mobile 1 &
Mobile 2
Single SIM mobile ports to connect to the GSM/UMTS
network.
LED Description Colour and Cadence
PWR Power LED. Turns on when
power is supplied
Green. continuous ON
STS Status LED. Blinks to indicate
health of the system.
Green. ON 1 second - OFF 1
second, on completion of
boot-up.

Matrix ETERNITY NE Specifications

General

Brand	Matrix
Model	ETERNITY NE
Category	PBX
Language	English
