Matrix ETERNITY NE Quick Start 11
Wireless WAN
• Make sure that
• You have installed a 3G UMTS module.
• a SIM is present in the Mobile port.
• Internet Services are activated on the SIM.
Connecting Extensions
Single Line Telephones (SLT)
• Use standard twisted wire pair the cables of good quality with RJ11 plugs to
connect the analog single line telephone instruments to the SLT ports, SLT1 -
SLT14 of ETERNITY NE.
• Place the SLTs, fax machine at the desired locations. Connect the SLTs, Fax
machine to the wall jacks.
• Plug the RJ11 end of the telephone cables into the SLT ports of ETERNITY NE.
Terminate the other end of the cables from the SLT ports on the wall jacks to
which the SLTs, fax machine are connected.
Connecting Digital Key Phones (DKP)
• ETERNITY NE supports 2 DKP ports, DKP1 and DKP2. You may connect
EON48, EONSOFT; or you may connect EON48 on one port and DSS64, the
DSS Console, on the other port.
