Matrix ETERNITY NE Quick Start Guide

Matrix ETERNITY NE Quick Start 13
Connecting SIP Extensions
When there is a VoIP module (optional) present in the ETERNITY NE, the
system allows registration of 16 SIP extensions.
You may register any SIP-enabled device like an IP-phone, a Soft phone,
Analog Phone Adapter, as the 'SIP Extension' of the ETERNITY NE.
You may also connect SETU VP248, the Extended IP Phone for ETERNITY as
SIP extension. The Extended IP Phone takes on all the functions of EON48, the
proprietary digital key phone.
The first 8 SIP extensions are free. To increase the number of SIP extensions, you will require the
IP8 License. Make sure you have a valid Key for this license when connecting more than 8 SIP
Extensions.
The SIP Extensions may be registered either over Ethernet WAN or over Wireless
WAN, according to your preference and your IP network installation scenario.
Ethernet WAN
If ETERNITY NE is connected to a Public Network,
• Connect SETU VP248, the Extended IP Phone, or any Open IP Phone to the
LAN Switch.
• Register any SIP client on the public network as SIP Extension.
When you register any SIP device, other than the Extended IP Phone, on the public network as
SIP Extension, you must configure the Registrar Server Address of ETERNITY NE, the Registrar
Server Port, the SIP ID, Authentication ID and Password in the SIP device.
