13
VEHICLE FRAME CUT FOR GPTLR-44 & GPTLR-55
FIG. 13-1
VEHICLE REQUIREMENTS - Continued
5-1/2”
13”
24”
TRUCK FRAME
BODY FLOOR
BODY CROSS
MEMBERS
REAR SILL
WOODEN SPACER
LONG SILL
PLATFORM CLEARANCE CUTOUT AREA
(WITHIN DASHED LINES)
