15
CENTER OF MASS
GPTLR-25 & GPTLR-33 CENTER OF MASS
(STOWED POSITION)
FIG. 15-1
12-3/4”
CENTER OF
MASS
8-1/2”
GPTLR-44 & GPTLR-55 CENTER OF MASS
(STOWED POSITION)
FIG. 15-2
CENTER OF
MASS
12-1/2”
8-1/2”
