Maxon GPTLR-44 - Removing Floor Jack and Lowering Platform

11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
43
STEP 10 - REMOVE LOCKING BRACKETS & CHECK
FOR INTERFERENCE
1. Remove fl oor jack and hoist
supporting Liftgate (FIG. 43-1).
REMOVING JACK
FIG. 43-1
FLOOR JACK
2. Lower platform to ground level
(FIG. 43-2). Refer to operating in-
structions in Operation Manual.
LOWERING PLATFORM
FIG. 43-2
