11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
7
GPTLR-SERIES INSTALLATION PARTS BOXES
PARTS BOX B WITHOUT POWER CABLE, GROUND CABLE, OR FRAME CLIPS
TABLE 7-2
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX B 1 297318-01
1 TOGGLE SWITCH ASSEMBLY 1 296855-01
2 INSTALLATION BRACKET 2 269462-01
3 HEX HEAD NUT, 1/2”-13 2 901011-9
4 SHIM, PLATFORM ADJUSTMENT, 1/8” 2 281166-02
5 SHIM, PLATFORM ADJUSTMENT, 1/16” 2 281166-01
6 SCREW, SELF TAPPING, #10-24 X 1-1/2” LG 2 900057-7
7 LUG, 2 GUAGE, COPPER, 5/16” 1 906497-02
8 CAP SCREW, HEX HEAD, 1/2”-13 X 1-1/2” LG. 2 900035-3
PARTS BOX A WITH POWER CABLE
TABLE 7-1
PARTS BOX C WITH GROUND CABLE
TABLE 7-3
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX C 1 297502-02
1 SPRING CLIP 20 050079
2 PLASTIC TIE 4 206864
3 GROMMET, 1” DIA, 2 HOLES 1 266428-09
4 CABLE ASSY, 175 AMP 38 FT LG 1 264422
5 GROUND CABLE ASSY, 2 GA X 38FT LG 1 269191-01
6 #10 LOOM CLAMP 2 801681
7 SELF-TAPPING SCREW, 10 X 1/2” LG. 2 030458
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX A 1 297502-01
1 SPRING CLIP 10 050079
2 PLASTIC TIE 2 206864
3 #10 LOOM CLAMP 2 801681
4 SCREW TAPPING #10 X 1/2” LG. 2 030458
5 GROUND CABLE ASSEMBLY, 2GA, 48” LG 1 251871-26
6 CABLE ASSEMBLY, 2GA, 49-3/4” LG. (GROUND) 1 268226-11
7 CAP SCREW, 5/16”-18 X 3/4” LG 1 900009-3
8 CABLE ASSEMBLY, 175A, 38 FT LG. 1 264422
