56
REMOVING LOCKING BRACKETS
FIG. 56-1
LOCKING
BRACKET
CAP NUT
FLAT
WASHER
BOLT
LH CYLINDER
RH
CYLINDER
LOCKING BRACKET
(2 PLACES)
19. Unbolt the locking brackets from
both cylinders (FIG. 56- 1). Re-
move the locking brackets.
STEP 11 - ADJUST PLATFORM (IF REQUIRED)
- Continued
