Specifications
Technical Data
IDX 70 User Manual
2-14 mmag | 2022-04 | rel10520
Mechanical
data
Dimensions (L x W x H) mm
141 x 70 x 70
176 x 70 x 70
211 x 70 x 70
Weight (approximate) g
1'600
2'300
3'000
Mounting — Flange-mounted (flange «A» or «C» to choose from)
Rotor inertia [d] gcm
2
568
1'050
1'534
Axial play at axial load mm 0.22
Radial play Preloaded ball bearings
Max. axial load, dynamic N 22
Max. radial load, 15 mm from flange N 300
Environment
Protection class — IP65 (IP54) [e]
Max. housing temperature °C 100
Operation temperature °C −30…+85 [f]
Storage temperature °C
−40…+35 (condensation not permitted)
Operation altitude [g] m MSL 0...1'000 [f]
Holding
brake
(optional)
Type — Spring-loaded brake, integrated into motor casing
Fall time (release time until brake
torque decreases)
ms 75
Rise time (engaging time until brake
torque is attained)
ms 75
Max. permissible static torque mNm 5'000
Backlash °m max. ±1
Length mm 38 [h]
Weight kg 0.460 [h]
Inertia (friction disk / hub) gcm
2
11 / 13 [h]
Continued on next page.
Parameter Unit
IDX 70 S IDX 70 M IDX 70 L
24 V 48 V 60 V
