Electrical Installation
Connections
IDX 70 User Manual
mmag | 2022-04 | rel10520
4-39
4.3.5.2 Logic Supply Voltage +V
C
(optional)
By default, the logic is powered by the regular supply voltage. Optionally, you may wish to feed the logic
supply voltage separately, permitting a safe and economical power backup feature.
Basically, any power source may be used, provided it meets the below stated minimal requirements.
Table 4-28 Logic supply requirements
4.3.5.3 Input/Output Supply Voltage +V
I/O
(optional)
Basically, any power source may be used, provided it meets the below stated minimal requirements.
Table 4-29 Input/output supply requirements
Logic supply requirements
Output voltage
+V
C
12…60 VDC
Absolute output voltage min. 10 VDC; max. 70 VDC
Min. output power
CANopen EtherCAT I/O
2.7 W 3.5 W 2.7 W
Input/output supply requirements
Output voltage
+V
I/O
24 VDC
Absolute output voltage min. 20 VDC; max. 30 VDC
Output current
Min: Depending on load at DigOUT1 and DigOUT2
Max: 1.5 A
