Electrical Installation
Connections
IDX 70 User Manual
mmag | 2022-04 | rel10520
4-41
Figure 4-24 USB connector X5
Table 4-30 USB connector X5 – Specification
Table 4-31 USB connector X5 – Pin assignment
Table 4-32 USB interface specification
For suitable prefab cable assemblies see Table 4-9 on page 4-27.
USB connector X5
Type USB Type “micro B”, female
X5
Pin
PC’s USB
Terminal
Signal Description
1 1 VBUS USB bus supply voltage (+5 VDC)
2 2 USB_D− USB data− (twisted pair with data+)
3 3 USB_D+ USB data+ (twisted pair with data−)
4 – ID Not connected
5 4 GND USB ground
USB
USB Standard USB 2.0 / USB 3.0 (full speed)
Max. bus supply voltage +5.25 VDC
Max. DC data input voltage −0.5…+3.8 VDC
