Electrical Installation
Status Indicators
IDX 70 User Manual
4-44 mmag | 2022-04 | rel10520
4.4.3 EtherCAT Port
The LEDs display the link activity of the EtherCAT port (applies for both ports, X1 “IN” and X2 “OUT”):
• Green LED indicates link activity
Table 4-36 EtherCAT port LED
LED
Description
Green
OFF Port is closed
Flicker Port is open / activity is present
ON Port is open
— Data rate is 100 Mbit/s
Flicker = continuous flickering (≈10 Hz)
