Water Level
NL: Normal Low level
NH: Normal High level
EL = Economic Low Level
EH = Economic High Level
Wash Action
Normal Wash Action
n A = 12 Seconds Action
n R = 3 Seconds Rest
Gentle Wash Action
n A = 3 Seconds Action
n R = 12 Seconds Rest
RPM (Revolutions Per Minute)
n W: Washing Speed (= 32–50 RPM)
n D: Distribution Speed (not changeable) (= 100 RPM)
n L: Low extraction speed, standard (= 400 RPM)
n H: High extraction speed (= 625–1165 RPM) (depending on
washer capacity)
PROGRAMMED CYCLES
The washer computer contains 20 pre-programmed Standard Wash
Programs. (Standard Programs: 1 to 20).
Programs 21 to 57 are special programs for North America.
NOTE: The programmed cycles are given as an example only.
Contact your soap supplier for assistance creating custom
programs.
Legend
Liquid Supply Times
The default liquid laundry product supply time is 30 seconds.
Water Inlet Valves
Washers with Top Laundry Product Dispensers
n Inlet Valve 1: Cold Soft Water (Soap Dispenser Compartment
“I” – Prewash
n Inlet Valve 2: Cold Soft Water Soap Dispenser Compartment “II”
Wash – Powdered Detergent
n Inlet Valve 3: Cold Soft Water Soap Dispenser Compartment “III”
Wash – Liquid Detergent
n Inlet Valve 4: Cold Soft Water Soap Dispenser Compartment
“Fabric Softener” – Last Rinse
n Inlet Valve 5: Hot Soft Water Soap Dispenser Compartment “I”
Prewash
n Inlet Valve 6: Hot Soft Water Soap Dispenser Compartment “II”
Wash – Powdered Detergent
n Inlet Valve 7: Cold Hard Water Direct Liquid Inlet
n Inlet Valve 8: Hot Soft Water Soap Dispenser Compartment “III”
Wash – Liquid Detergent
