CENTER CONSOLE Cont’d
1995-96 Cont’d
17
Insulator, Floor¶
Man Trans B455-68-643B
18
Brkt, Rear Console¶
BC1D-64-416
19
Boot, Brake Lever¶
w/Rear Lid BC1G-64-432A
w/o Rear Lid BC1D-64-432
20
Cover, Hole¶
Brown R BC1F-55-225-90
L BC1E-55-225-90
Gray R BC1F-55-225-09
L BC1E-55-225-09
¶Included w/Rear Console Assy
1997-98
1
Console Assy, Front
Man Trans
Brown B21J-64-320B-90
Gray B21J-64-320B-09
Auto Trans
Brown B21H-64-320B-90
Gray B21H-64-320B-09
2
Boot, Shift¶
Man Trans B21J-64-330
¶Included w/Front Console Assy
3
Fastener, Console
Beige R/L B467-68-AC3-43
Gray R/L B467-68-AC3-07
4
Console Assy, Rear
w/Rear Lid
Brown B16A-64-420A-90
Gray B16A-64-420A-09
w/o Rear Lid
Brown B16M-64-420-90
Gray B16M-64-420-09
5
Lid Assy, Rear¶
Brown BC1G-64-450B-90
Gray BC1G-64-450B-09
6
Lock, Lid¶ (a)
BC1G-64-45YA
7
Hinge, Lid¶ (a)
BC1G-64-45XB
(a) Included w/Rear Lid Assy
8
Cover, Rear Hole¶
Brown B16A-64-424-90
Gray B16A-64-424-09
9
Boot, Brake Lever¶
w/Rear Lid BC1G-64-432A
w/o Rear Lid BC1D-64-432
10
Cover, Front Hole¶
Brown R BC1F-55-225-90
L BC1E-55-225-90
Gray R BC1F-55-225-09
L BC1E-55-225-90
¶Included w/Rear Console Assy
11
Bracket, Rear Console
B02B-64-416
ROCKER/PILLARS/FLOOR
SHEET METAL
HATCHBACK
Illustration Located in Next Column
1
Pillar, Outer Hinge
R/L N.A.
Antenna, Radio
N.A.
2
Panel, Outer Rocker
R/L N.A.
3
Reinf, W/S Pillar
R/L N.A.
4
Reinf, Hinge Pillar
R/L N.A.
5
Pillar, Inner Hinge
R/L N.A.
6
Reinf, Cowl Side
R/L N.A.
SHEET METAL
SEDAN
1
Pillar, Outer Hinge
R B0YB-70-221
L BCYD-71-220
Antenna, Radio
BC1D-66-930C
2
Pillar, Outer Center
R B0YW-70-351
L B0YW-71-351
3
Panel, Outer Rocker
R B0YW-70-271
L B0YW-71-271
4
Reinf, W/S Pillar
95-96 R BC1D-70-242
L BC1D-71-242
97-98 R B01W-70-242
L B01W-71-242
5
Reinf, Hinge Pillar
R BC1D-70-030
L BC1D-71-030
6
Pillar, Inner Hinge
R BC1D-70-24X
L BC1D-71-24X
7
Reinf, Cowl Side
R BC1E-70-65Z
L BC1E-71-65Z
8
Reinf, Center Pillar
R BC1D-70-38XA
L BC1D-71-38XA
9
Pillar, Inner Center
95 R BC1D-70-080A
L BC1D-71-080A
96-98 R BC1D-70-080A
L BC1D-71-080A
FRONT FLOOR
1
Panel, Inner Rocker
Hatchback R/L N.A.
Sedan R BC1D-53-950E
L BC1D-54-950D
2
Pan, Front Floor
BCYD-53-600
3
Unirail, Front-See Front Inner Structure Section
INTERIOR TRIM
HATCHBACK
1
Mldg, W/S Garnish-See Windshield Section
2
Trim, Cowl Panel
Brown R/L N.A.
Gray R/L N.A.
3
Plate, Scuff
R/L N.A.
4
Trim, Seat Side
Black R/L N.A.
Brown R/L N.A.
INTERIOR TRIM
SEDAN
1
Mldg, W/S Garnish-See Windshield Section
2
Trim, Cowl Panel
Brown R BC1D-68-370B-90
L BC1D-68-390E-90
Gray R BC1D-68-370B-09
L BC1D-68-390E-09
3
Trim, Ctr Pillar Upper
Brown R BC1D-68-190-90
L BC1D-68-210-90
Gray R BC1D-68-190-06
L BC1D-68-210-06
4
Trim, Ctr Pillar Lower
1995-96
Brown R B21H-68-220-90
L B21H-68-230-90
Gray R B21H-68-220-09
L B21H-68-230-09
1997-98
Brown R B21H-68-220-90
L B21H-68-230-90
Gray R B21H-68-220-09
L B21H-68-230-09
5
Plate, Front Scuff
To Next Page
