16 Extension, Rear Floor R NC10-53-741B
L NC10-54-741A
17
Bracket, Jack N067-53-79XB
18
Crossmember, Rear Floor NC10-53-931
19
Reinf, Rear Floor NC10-53-728
20
Rail Assy, Rear R NC10-53-810F
L NC10-54-810F
21
Rail, Rear¶ R NC10-53-811A
L NC10-54-811A
22
Reinf, Rear Rail¶ R/L NC10-53-82Z
23
Bolt, Front Rail¶ R/L 9YA9-91-201A
24
Bolt, Rear Rail¶ R/L 9YA9-91-203
25
Bracket, Rear Bumper¶ R/L NC10-53-89XA
26
Bracket & Hook¶ R NC10-53-890A
L NC10-54-890A
¶Included w/Rear Rail Assy
27
Pan, Center Floor 99-02 N067-53-720A
03-04 N067-53-720B
28
Gusset, Center Floor 99-00 NC10-54-770A
01-04 N067-54-770B
29
Xmbr, Center Floor 99-00 NC72-53-900
01-02 NC72-53-900B
03-04 ND30-53-900
30
Brkt, Brake Cable NA01-53-819
31
Brkt, Fuel Tank NA01-54-780
INTERIOR TRIM
Illustration Located in Next Column
1
Panel, Rear End Trim 99-00 NC10-68-891A-04
01-04 NC72-68-891-04
2
Cap, Rear End Trim R/L KA01-68-86YA
3
Trim, Side Trunk R NC10-68-851-04
L NC10-68-871-04
4
Fastener, Trim (14)
Beige GJ21-68-885B-80
Black GJ21-68-885B-02
Tan GJ21-68-885B-21
5
Board, Aero
1999-03
Beige 01-03 N053-68-3X0E-80
Black NC10-V1-260F-02
Tan 99-02 N053-68-3X0E-21
6
Board Assy, Aero
2004
w/Rear Speaker
w/Bose Speaker System
Beige
To 1-1-04 NE06-68-3X0A-80
From 1-1-04 NE06-68-3X0B-80
Black
To 1-1-04 NE06-68-3X0A-02
From 1-1-04 NE06-68-3X0B-02
w/o Bose Speaker System
Beige NE01-68-3X0B-80
Black NE01-68-3X0B-02
w/o Rear Speaker
Beige NE45-68-3X0A-80
Black NE45-68-3X0A-02
7
Cover, Speaker¶
Beige R NE01-68-84XA-80
L NE01-68-86XA-80
Black R NE01-68-84XA-02
L NE01-68-86XA-02
8
Spring, Mounting¶
1999-03 R/L J001-64-345
2004
To 8-18-03 R/L J001-64-345
From 8-18-03 R/L S47P-64-345
9
Speaker, Rear¶
w/Bose Speaker System R/L NE02-66-960A
w/o Bose Speaker System R/L NE01-66-960A
10
Bracket, Speaker¶ R/L NE02-66-9B1A
11
Amplifier, Radio¶
To 1-1-04 NE02-66-92XA
From 1-1-04 NE02-66-92XB
¶Included w/Aero Board Assy
12
Bracket, Board
1999-03
Beige 01-03 R N053-68-3CX-80
L N053-68-3CY-80
Black R N053-68-3CX-02
L N053-68-3CY-02
Tan 99-02 R N053-68-3CX-21
L N053-68-3CY-21
2004
Beige R NE01-68-3CX-80
L NE01-68-3CY-80
Black R NE01-68-3CX-02
L NE01-68-3CY-02
13
Cover, Seat Belt
1999-03
Beige 01-03 R N053-68-3R1C-80
L N054-68-3R1C-80
Black R N053-68-3R1C-02
L N054-68-3R1C-02
Tan 99-02 R N053-68-3R1C-21
L N054-68-3R1C-21
2004
Beige R NE01-68-3R1A-80
L NE02-68-3R1A-80
Black R NE01-68-3R1A-02
L NE02-68-3R1A-02
14
Trim, Package Tray¶
Sport, Std Pkg
Black NC10-68-3F1E-02
Tan NC10-68-3F1E-21
10th Anniversary Pkg N055-68-3F1-55
¶Order by Application
15
Fastener, Trim (8/Side)
Beige G032-68-865A-80
Black G032-68-865A-00
Tan G032-68-865A-39
REAR LAMPS
COMBINATION LAMP
1 Lamp Assy, Combination 99-00 R NC10-51-150C
L NC10-51-160C
01-04 R N066-51-150
L N066-51-160
2
Lens & Body¶ 99-00 R NC10-51-170C
L NC10-51-180C
01-04 R N066-51-170
L N066-51-180
3
Socket & Wire¶ 99-00 R/L NC10-51-155
01-04 R/L N066-51-155
4
Bulb¶
Back-Up R/L 9970-06-210
Signal R/L 9970-06-210Y
Stop/Tail R/L 9970-08-215
5
Gasket¶
Outer R/L H432-51-158
Inner R/L N066-51-158
¶Included w/Combination Lamp Assy
6
Grommet R/L GA7B-51-146
SIDE MARKER LAMP
1 Lamp Assy, Side Marker R NC10-51-5H0A
L NC10-51-5J0A
2
Screw, Lamp¶ (2/Side) R/L 9976-80-420
¶Included w/Side Marker Lamp Assy
3
Nut, Lamp (2/Side) R/L G158-50-803
LICENSE LAMP
1 Lamp Assy, License R/L NC10-51-270B
2
Gasket¶ R/L NC10-51-273A
3
Socket¶ R/L NC10-51-272
4
Bulb¶ R/L 0000-11-0194
¶Included w/License Lamp Assy
HIGH MOUNT STOP LAMP
1 Lamp Assy, Stop NC10-51-580C
2
Gasket¶ NC10-51-592A
3
Socket¶ NA12-51-584A
4
Bulb¶ 9970-13-210
¶Included w/Stop Lamp Assy
