7 CONFIGURATION
7.1 Web-based Configuration
This section will show you how to configure your bb100 using the web-based configuration interface. The
default network settings are the following:
Default Internet Connection Type: DHCP
Default PC Port Connection Type: Bridge
Default user name of admin mode: admin
Default user name of user mode: user
Default password of Web: (null)
Default Web login port: 8080
Web Idle Timeout: 5 min
7.2 Login
To access the phone through a web browser
Step 1: Setup bb100 correctly
Step 2: Lookup the Internet IP Address in the left side of LCD
Step 3: Enter “http://Internet IP Address:8080” in the address field of the browser.
Step 4: Type “admin” or “user” for the User Name, click on the Login button to access the
configuration page
There are two levels of web configuration: one “user” ID level that can view just some portion in the web,
and the other “admin” ID level that can view and configure all settings in the web-based configuration
interface. To use “admin” ID for login, please contact your administrator, supplier or service provider.
7.3 Webpage
No. Name Description
1 Main information Display the firmware version,
DSP version, Current Time, and
administration mode.
Press Logout button to logout.
2 Navigation bar Click navigation bar, many sub-
navigation bar will appear in
the place 4.
3 Help Display the main information
for configuration; user can get
help from it directly.
4 Sub-navigation bar Click sub-navigation bar to
enter to configuration webpage
5 Configuration title The configuration title
6 Configuration bars The configuration bars
