3.3.2 Main screen
Figure 9
The front panel allows the operator to display all the data of the working cycle. The following
elements can be seen on the panel:
1. ON/OFF: system switch-on and switch-off.
2. Menu: press it once to go to the next screen; press and hold down to switch to
the programming mode.
3. UP: increases the selected value.
4. DOWN: decreases the selected value.
5. OK : selects the parameter to be changed
