MC Electronics GLM KIT - Work Screen

Instructions for use
GLM KIT
16
3.5 Work screen
Figure 11
1. Speed: Work speed indicator, if the sensor is present.
2. Splitting bar: selecting this parameter allows to split the width of the work bar.
Splitting the object can be done up to 4 sections.
3. Fan RPM value: the system displays the RPM value of the fan, if the sensor is
present.
4. Destemmer paddle RPM value: the system displays the RPM value of the
destemmer paddle, if the sensor is present.
5. Counter ha/h: Indicates the average of the hectares worked per hour, if the
sensor is present.
6. Variable range: This area allows you to display one of the parameters indicated
below, depending on the selection made:
- Partial work area, if the speed sensor is present;
- Total work area, if the speed sensor is present.
7. Multiplicative factor for the recovery sensors calculation, if present
8. Multiplicative factor for the straw walker sensors calculation
9. Multiplicative factor for the sieves sensors calculation
3
1
2
4
5
6
7
8
9
