2. General description
GLM kit is a system that allows to increase the performance of the combine harvester (in
ha/h) installing sensors in the sieves and straw walker. It is also possible to add an
optional sensor inside the recovery channel in order to allow the operator to adjust the
sieves with precision. By means of a graphical interface with histograms and buzzer it will
inform the operator when losses exceed the set loss threshold in order to achieve
maximum operation speed.
The system only operates with the ECU GLM control unit:
Figure 1 - ECU GLM (code 40CEN-GLM-0001)
CALIBRATE THE LOSS SENSORS PRIOR TO USE:
1) WITH THE MACHINE STATIONARY, BRING THE SYSTEM TO THE
MAXIMUM OF THE REVS.
2) WORK SCREEN GRAPHS MUST NOT INDICATE LOSSES.
