Instructions for use
GLM KIT
30
11. Technical data
11.1 3.5” Virtual Terminal
Power supply voltage
: 10 ÷ 32 Vdc
Maximum energy consumption
: 150 mA
Operating features
Protection rating
: IP65
Mechanical vibrations resistance
: 2G
Operating conditions
Room temperature
: -20°C - 70°C
Weather conditions
: Relative humidity 80%
Transport and storage
Temperature
: -25°C ÷ 70°C
11.2 ECU GLM
Power supply voltage
: 12 Vdc
Absorbed current in stand-by
: < 200 uA
Maximum energy consumption
: 2 A
Operating temperature
: -20°C ÷ 70°C 80%
Protection rating
: IP65
Digital inputs
: 6 for frequency inputs for sensor losses
1 for NPN max 500 Hz (type 1)
3 for NPN max 3 kHz (type 2)
Output
: 3 for frequency outputs for sensor losses
Communication line
: 1 x CAN BUS 2.0B (500 kbit/s)
