Instructions for use
GLM KIT
17
3.6 Screen of sensor sensitivity
Figure 12
1. Speed: Work speed indicator, if the sensor is present.
2. Splitting bar: selecting this object allows to split the length of the work bar.
Splitting the object can be done up to 4 sections.
3. Fan RPM value: the system displays the RPM value of the fan, if the sensor is
present.
4. Destemmer paddle RPM value: the system displays the RPM value of the
destemmer paddle, if the sensor is present.
5. Counter ha/h: Indicates the average of the hectares worked per hour.
6. Variable range: This area allows you to display one of the parameters indicated
below, depending on the selection made:
- Partial work area, if the speed sensor is present;
- Total work area, if the speed sensor is present.
7. Recovery sensors sensitivity: allows to calibrate the sensitivity of the recovery
sensors, if present.
8. Straw walker sensors sensitivity: allows to calibrate the sensitivity of the straw
walker sensors.
9. Sieves sensors sensitivity: allows to calibrate the sensitivity of the sieves
sensors
1
2
3
4
5
6
7
8
9
