Output Wiring Connection
3.2 4-20mA Connection To Water Specialties Instrumentation
IN60 – Flow Computer
Connection To Connection
IN60 Term. Strip Pin 16 (Iso. +12 VDC) FC101 Output Cable Red (+)
IN60 Term. Strip Pin 4 (input) FC101 Output Cable Blk (-)
IN41 – 10” Chart Recorder
Connection To Connection
IN41 TB-2 (-) FC101 Output Cable Red (+)
IN 41 TB-2 (+) Separate 24 VDC Supply (+)
Separate 24 VDC Supply (-) FC101 Output Cable Blk (-)
IN48 – 12” Chart Recorder (Sold After 05/1993)
Connection To Connection
IN48 J11 (+) FC101 Output Cable Red (+)
IN48 J11 (-) IN48 J2 (-)
IN48 J2 (+) FC101 Output Cable Blk (-)
IN48 – 12” Chart Recorder (Sold Before 05/1993)
Connection To Connection
IN48 J6 (+) FC101 Output Cable Red (+)
IN48 J6 (-) IN48 J10 (-)
IN48 J10 (+) FC101 Output Cable Blk (-)
250 Ohm resister from IN48 J6 (+) and IN48 J6 (-)
