McCrometer WATER SPECIALTIES FlowCom FC101 User Manual

30119-50 Rev. 2.2 | 23JUL2020
Page 38
TROUBLESHOOTING
7.1 Circuit Board Connections
The circuit board does not have any serviceable components. Each register is shipped with the cables connected to the
appropriate input and output connections per the customer requirements. The circuit board layout is contained in this
manual as a technical support reference manual as a technical support reference.
Figure 20. FlowCom Circuit Board
RED
BLACK
Sensor Input
Connection
corrected 1-22-19
