McCrometer WATER SPECIALTIES FlowCom FC101 User Manual

30119-50 Rev. 2.2 | 23JUL2020
Page 30
PROGRAMMING
Conguration Settings:
Menu Item Display Menu Item Description Item Selection
rAtE-Un Rate Unit CFS
rAtE-dP Rate Format 888.88
tot-Un Totalizer Unit AFT
tot-dP Totalizer Decimal Place 0.000
tot-Fact Totalizer Multiplier
(Not applicable with a tot-dP setting)
20mA-Un 20 mA Unit CFS
20mA-dP 20 mA dp 0.0
20mA-FS 20 mA FS 2.5
PLS-Un Pulse Units GAL
PLS-dP Pulse Decimal Place 0
PLS-Inc Pulse Increment 1000
SErno Reg. Serial Number
(Serial number is set at the factory)
GPr-dP GPR Decimal Place 0.0000
GPr Gallons Per Rev 1.4815
Smooth Smoothing t1
4mA-AdJ Trim 4mA .00 (Adjusted during 4-20mA calibration)
20mA-AdJ Trim 20mA .00 (Adjusted during 4-20mA calibration)
PLS-tYPE Pulse Type rEL
PLSwidth Pulse Width
(Not applicable for the dry contact switch output)
Au-InP Auxiliary Input nonE
Cut-dP Low-Flow Cuto DP 0
CutoFF Low-Flow Cuto 0
PLS-Pr Pulse Per Rev 2
4.5 Conguration Examples
Example 1: Register With DC-powered Optically-isolated O.C. Pulse Output
Meter Size : 6”
Gallons Per Revolution: 1.4815
Rate Units: Cubic Feet per Second
Totalizer Units: Acre Feet x 0.001
4-20mA Full Scale: 2.5 CFS
Switch Closure Output: 1 Switch for Every 1000 Gallons
Sensor Type: 2 PPR
Note:
1. The dry contact switch pulse output commonly used on Scada and irrigation systems. The dry contact switch pulse
length is not adjustable.
