McCrometer WATER SPECIALTIES FlowCom FC101 User Manual

30119-50 Rev. 2.2 | 23JUL2020
Page 31
PROGRAMMING
Conguration Settings:
Menu Item Display Menu Item Description Item Selection
rAtE-Un Rate Unit MGD
rAtE-dP Rate Format 8888.8
tot-Un Totalizer Unit GAL
tot-dP Totalizer Decimal Place
(Not applicable with a tot-Fact setting)
tot-Fact Totalizer Multiplier X 10000
20mA-Un 20 mA Unit GAL
20mA-dP 20 mA dp 0
20mA-FS 20 mA FS 0 (4-20mA full scale not dened)
PLS-Un Pulse Units AFT
PLS-dP Pulse Decimal Place 0.00
PLS-Inc Pulse Increment 0.01
Par-Ser Parent Serial Number
(Serial number is set at the factory)
SErno Reg. Serial Number
(Serial number is set at the factory)
GPr-dP GPR Decimal Place 00000
GPr Gallons Per Rev 37
Smooth Smoothing t1
4mA-AdJ Trim 4mA .00 (Adjusted during 4-20mA calibration)
20mA-AdJ Trim 20mA .00 (Adjusted during 4-20mA calibration)
PLS-tYPE Pulse Type OC
PLSwidth Pulse Width 0.1
Au-InP Auxiliary Input nonE
Cut-dP Low-Flow Cuto DP 0
CutoFF Low-Flow Cuto 0
PLS-Pr Pulse Per Rev 2
Note:
1. Optically-isolated open collector and dry contact switch closure outputs are not applicable because they both require
DC power. The pulse width length is an option only for the standard open collector pulse output.
Example 2: Register With Battery-powered O.C. Pulse Output
Meter Size : 24”
Gallons Per Revolution: 37.0
Rate Units: MGD
Totalizer Units: Gallons x 10000
Open Collector Pulse Output: 1 Pulse for Every 0.01 Acre Foot
Pulse Width: 0.1 milliseconds
Sensor Type: 2 PPR
