PRODUCT SPECIFICATIONS
5.0 PRODUCT SPECIFICATIONS
5.1 Specications
Environmental 4-20mA Analog
Operating Temp.: -4°F to 158°F (-20°C to 70°C) Power Requirements: 12 to 30 VDC
Storage Temperature: -40°F to 158°F (-40°C to 70°C) Transmission: 5,000 feet max.
Housing Rating:
Meter Rating (with
Remote Mount):
NEMA 4X
IP67
4mA/20mA Trim: .01 mA to .50 mA
Input Signal
Engineering/Time Units: 22 dierent units
Input Compatibility: McCrometer Flowmeters
Pulse Outputs
Remote Distance: 50 feet max.
Engineering Units: 20 dierent units
Rate Functions
Optically Isolated Pulse
Display: 5-digit Collector to emitter voltage: 50V @ 50 mA max.
Rate Units: 22 dierent units Pulse Width: 80 ms
Totalizer Functions Max Pulses Per Minute: 30
Display: 8-Digit Signal Distance: 500 feet max.
Totalizer Units: 20 dierent units Open Collector Pulse
Accuracy: 0.25% Collector to emitter voltage: 50V @ 50 mA max.
Non-Volatile Storage: Updated hourly Pulse Width: adjustable
Scaling Factor: .0001 to 10000
Max Pulses Per Minute: 150
Programming
Signal Distance: 500 feet max.
Program Access: Magnetic wand (included) Contact Closure
Programming: Menu driven Contact Rating: 30V @ 1 Amp Max.
Access Lockout: 5-digit code Pulse Width: 80 ms
Test Modes: 4 mA and 20 mA test modes Max Counts Per Minute: 30
Totalizer Reset: Programming
Signal Distance: 500 feet
Total Reset Disable: Programming (permanent)
Power Requirement
Calibration Adjustment: ± .01% to 10%
Battery Type: Lithium 3.6 V
Battery Life: 6 - 10 Years
Optional 4-20mA: Loop powered
