PROGRAMMING
Example 3: Register With 4-20mA Transmitter Output
Meter Size : 4”
Gallons Per Revolution: 0.5
Rate Units: Liters Per Hour
Totalizer Units: Metric Ton x 1
4-20mA FS: 100 LPM
Sensor type: 2 PPR
Conguration Settings:
Menu Item Display Menu Item Description Item Selection
rAtE-Un Rate Unit Un 14 (No symbol on display)
rAtE-dP Rate Format 88888
tot-Un Totalizer Unit Un 7 (No symbol on display)
tot-dP Totalizer Decimal Place 0
tot-Fact Totalizer Multiplier X 1
20mA-Un 20 mA Unit Un 7 (Un 7 is an reference to a rate unit)
20mA-dP 20 mA dp 0
20mA-FS 20 mA FS 100
PLS-Un Pulse Units GAL
PLS-dP Pulse Decimal Place 0
PLS-Inc Pulse Increment 0 (No pulse output dened)
Par-Ser Parent Serial Number
(Serial number is set at the factory)
SErno Reg. Serial Number
(Serial number is set at the factory)
GPr-dP GPR Decimal Place 0000.0
GPr Gallons Per Rev 0.5
Smooth Smoothing t1
4mA-AdJ Trim 4mA .00 (Adjusted during 4-20mA calibration)
20mA-AdJ Trim 20mA .00 (Adjusted during 4-20mA calibration)
PLS-tYPE Pulse Type Opt (Type is irrelevant since there the pulse increment is not dened)
PLSwidth Pulse Width
(Not applicable for the optically-isolate open collector pulse output)
Au-InP Auxiliary Input nonE
Cut-dP Low-Flow Cuto DP 0
CutoFF Low-Flow Cuto 0
PLS-Pr Pulse Per Rev 2
Note:
1. In this example, units of measures “Un XX” are used at three dierent settings. There will not be any unit of measure
symbol on the display. The cumulative total is using “Un 7” from the set of total units, and the 4-20mA is using “Un 7” from
the set of rate units.
To Next Page
