30119-50 Rev. 2.2 | 23JUL2020
Page 19
PROGRAMMING
4.3 Menu Table Of Contents
First Menu Level
Display Menu Title Description
0 Loc-CodE
Program Lock
Out
Enter w/preset
code
1 rAtE-Un Rate Unit/Time Sets Unit/Time
2 rAtE-dP Rate Format
Sets Rate Decimal
Place
3 tot-Un Totalizer Unit Sets Unit
4
tot-dP-E
*
Totalizer Decimal
Point Enable
Enables/Disables
Totalizer Decimal
Point
5
tot-dP
*
Totalizer Decimal
Place
Sets Decimal
Place
Tot-FAct
*
Totalizer
Multiplier
Sets Multiplier
6 20mA-Un 20mA Unit Sets 20mA Unit
7 20mA-dP 20mA DP
Sets 20mA
Decimal Place
8 20mA-FS 20mA FS 20mA Full Scale
9 PLS-Un Pulse Unit Sets Pulse Unit
10 PLS-dP
Pulse Decimal
Place
Sets Pulse
Decimal Place
11 PLS-Inc Pulse Increment Sets Pulse Value
12 CAL-Pct
Calibration
Percent
Adjusts Meter
Accuracy
13 -Go to
Go to Menu or
Run
* If tot-dP-E (Totalizer Decimal Point Enable) is disabled
(turned o), tot-dP (Totalizer Decimal Place ) will not
be accessible.
* If tot-dP-E (Totalizer Decimal Point Enable) is enabled
(turned on), Tot-FAct (Totalizer Multiplier) will not be
accessible.
** PLSwidth (Pulse Width) is only accessible when OC
is selected in the PLS-tYPE menu (Pulse Type).
Second Menu Level
Display Menu Title Description
1 Par-S
Parent Meter
Serial #
Sets Meter Serial
No.
2 SErno Register Serial #
Sets Register
Serial No.
3 Set-CodE Set Lock Code
Sets new Lock
Code
4 GPr-dP
GPR Decimal
Place
Sets GPR Decimal
Place
5 GPr
Gallons Per
Revolution
Sets GRR Digits
6 Smooth Smoothing
Turns Smoothing
on/o
7 4mA-AdJ Trim 4mA Adjusts 4mA Zero
8 20mA-AdJ Trim 20mA Adjusts 20mA FS
9 PLS-tYPE Pulse Type Sets Pulse Type
10
PLSwidth
**
Pulse Width
Sets Pulse Width
in ms
11 RESEttot Reset Total Zeroes Total
12 DIS-rSt
Disable Reset
Total
Permanent Reset
Disable
13 tot-S Set Total Sets Total
14 Au-InP Auxiliary Input
Sets operation of
input
15 cuto Low Flow Cuto Sets Min. Flowrate
16 PLS-Pr
Pulses per
Revolution
Sensor Pulses per
rev.
17 -Go to
Go to Menu or
Run
