McIntosh C2200 User Manual

18
Firmware Version
The C2200 functionality is controlled by internal software
that is know as Firmware. The Version of the Firmware in
the C2200 can be identified at any time by utilizing the
Setup Mode.
1. Press the SETUP Push-button to access the Setup
Mode.
2. Rotate the Front Panel METER LIGHTS (Menu) Con-
trol until the word VERSION _. _ _ appears. Refer to
figure 23.
3. The number after the word VERSION is the Firmware
number.
4. Press the SETUP Push-button to exit the Setup Mode.
Figure 23
Default Title New Title Trim Trigger
AUX
TUNER
CD2
CD
DVD
SAT
VCR
TAPE
Input Source Settings
Setup, con’t

McIntosh C2200 Specifications

General

Type	Tube Preamplifier
Total Harmonic Distortion	0.08%
Output	2.5V
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Input Impedance	47K ohms
Dimensions	17.5" (44.5cm) x 7" (17.8cm) x 18" (45.7cm)
Tube Complement	12AT7
Inputs	1 (phono)
Outputs	3
Gain	15dB
