McIntosh C2200 User Manual

6
Dimensions
The following dimensions can assist in determining the best
location for your C2200. There is additional information on
the next page pertaining to installing the C2200 into cabi-
nets.
Dimensions
17- 1/2 "
44.45cm
6 - 5/16 "
16.03cm
7 - 5/8 "
19.37cm
16- 3/16 "
41.43cm
3/16 "
0.48cm
13 - 1/4 "
33.66cm
17"
43.18cm
Front View of the C2200
Rear View of the C2200
Side View of the C2200
7 - 1/8 "
18.10cm
13/16 "
2.06cm
6- 1/2 "
16.51cm
10- 1/2 "
26.67cm
15- 1/2 "
39.37cm
2"
5.08cm

McIntosh C2200 Specifications

General

Type	Tube Preamplifier
Total Harmonic Distortion	0.08%
Output	2.5V
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Input Impedance	47K ohms
Dimensions	17.5" (44.5cm) x 7" (17.8cm) x 18" (45.7cm)
Tube Complement	12AT7
Inputs	1 (phono)
Outputs	3
Gain	15dB
