C2800
The supplied C2800 Remote Control (HR085)
is capable of directly controlling the functions
of contemporary McIntosh Source Components
connected to the C2800 via the Data Ports.
Notes: 1. If at any time the C2800 seems unresponsive to the
HR085 Remote Control Commands, press the DEVICE
Button to select first.
2. For additional information on using the HR085 Remote
Control with the McIntosh Model, please refer to the “How
to Operate” starting on page 20.
3. For additional information on assigning the Data Ports,
refer to “Data Ports” on page 13.
Trim
Press the TRIM Button until the desired Trim
function (Balance, Trim Level, etc.) appears on the
C2800 Front Panel Display, then press the LEVEL
Up or Down Button to adjust the Trim setting.
Note: Press the TRIM Button to recall the last Trim function
selected. For additional information on using the Trim
Functions refer to pages 18-19.
Output Selection
Press the BLUE (Setup) Button followed by the
AM (Output 1) or FM (Output 2) Button, to control
the Rear Panel Audio OUTPUTS 1, 2 (ON or OFF)
and Power Control TRIG 1 / TRIG 2.
Note: For additional information on assigning the Outputs (1 and
2) and Power Control Triggers (1 and 2) refer to page 3.
How to use the Remote Control
The supplied HR085 Remote Control is capable of
directly controlling the functions of contemporary
Source Components connected to the C2800 via
the Data Ports.
Note: If at any time the C2800 seems unresponsive to HR085
Remote Control Commands press the
Button first.
Mute
Press the MUTE Button to mute the audio in all
outputs except the SEND OUTPUT. The word
MUTE will appear on the Front Panel Information
Display. To un-mute the audio, press the MUTE
Button again.
Disc, Server and Tape Functions
Use these buttons to operate a DVD Player, CD
Player, CD Changer, Music Server or Recorder.
Numbered Buttons
Press Buttons 0 through 9 to access tuner station
presets, tracks on discs or selections on a Music
Server.
Disc and Track
Use the AM (disc) and FM (track) Buttons when a
Disc Player or Music Server is being used.
Tuner But tons
Press the AM or FM Button to select the desired
broadcast band. Press and release the Channel Up
p or Down q Button to seek the next available
station. Press and hold a Channel Up p or Down
q Button to seek continuously from station to
station.
Volume
Press the Up p or Down q VOLUME Button to
raise or lower the listening volume level.
Note: The Record Signals present at REC OUTPUTS are not
affected by volume changes.
Pause
Press the Pause Button to perform various
functions on a variety of McIntosh Components. It
will also pause the playing of a disc or tape player.
Trim
Press the TRIM Button until the desired Trim
function (Balance, Trim Level, etc.) appears on
the Front Panel Information display, then press the
LEVEL Up p or Down q Button to adjust the
Trim setting.
Note: Press the TRIM Button to recall the last Trim Function
selected. For additional information on the Trim Functions
refer to pages 18 and 19.
Amplier Selection
Press the BLUE (Setup) Button followed by the
AM (Output 1) or FM (Output 2) Button, to control
the rear panel Audio OUTPUTS 1, 2 (ON or
OFF) and Power Control OUTPUT 1 / OUTPUT
2. These OUTPUTS provide signals to a Power
Amplier or other accessory component.
