41
Amplifier Specifications
Photos and Specifications
Power Output
300 watts is the minimum sine wave continuous aver-
age power output per channel, both channels operating
Output Load Impedance
2, 4 or 8 ohms
Rated Power Band
20Hz to 20,000Hz
Total Harmonic Distortion
0.005% maximum with both channels operating from
250 milliwatts to rated power, 20Hz to 20,000Hz
Dynamic Headroom
1.8dB
Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Preamplifier Output 1 and 2 (for rated input)
1.7V unbalanced Output 1 (8V Maximun)
3.4V balanced Output 2 (16V Maximun)
Sensitivity (for rated output)
High Level, 300mV unbalanced, 600mV balanced
Phono MM, 3.0mV
Phono MC, 0.30mV
Power Amp In, 1.7V
Signal To Noise Ratio (A-Weighted)
High Level, 98dB below rated output
Phono MM, 84dB below 5mV input
Phono MC, 82dB below 0.5mV input
Power Amplifier, 114dB below rated output
