24 AGZ 010B through 034B IOMM AGZB1
Table 12, AGZ 010 034A, Compressor & Fan Motor Amps, R-407C
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
AGZ
Unit
Size
Volts
No. 1 No. 2
F.L. Amps
Fan
Motor
(Each)
No. of
Fans
Fan
Motor
(Each)
No. 1 No. 2
208
20.3 20.3
5.8 2 21.4 156 156
230
18.6 18.6
5.8 2 23.7 156 156
460
9.2 9.2
2.8 2 10.7 75 75
010B
575
7.4 7.4
2.5 2 11.0 54 54
208
28.8 28.8
5.8 2 21.4 195 195
230
28.8 28.8
5.8 2 23.7 195 195
460
14.7 14.7
2.8 2 10.7 95 95
013B
575
10.8 10.8
2.5 2 11.0 80 80
208
31.2 31.2
5.8 2 21.4 225 225
230
30.1 30.1
5.8 2 23.7 225 225
460
15.5 15.5
2.8 2 10.7 114 114
017B
575
12.1 12.1
2.5 2 11.0 80 80
208
42.3 42.3
5.8 3 21.4 245 245
230
42.3 42.3
5.8 3 23.7 245 245
460
18.6 18.6
2.8 3 10.7 125 125
020B
575
14.6 14.6
2.5 3 11.0 100 100
208
49.4 49.4
5.8 3 21.4 300 300
230
49.4 49.4
5.8 3 23.7 300 300
460
23.1 23.1
2.8 3 10.7 150 150
025B
575
19.2 19.2
2.5 3 11.0 109 109
208
57.9 57.9
5.8 3 21.4 340 340
230
53.8 53.8
5.8 3 23.7 340 340
460
28.2 28.2
2.8 3 10.7 173 173
029B
575
22.4 22.4
2.5 3 11.0 132 132
208
75.0 75.0
5.8 3 21.4 505 505
230
73.1 73.1
5.8 3 23.7 505 505
460
34.0 34.0
2.8 3 10.7 225 225
034B
575
28.8 28.8
2.5 3 11.0 180 180
NOTE: See page 26 for all Electrical Data notes.
