20 AGZ 010B through 034B IOMM AGZB1
Electrical Data
Field Wiring
Wiring must comply with all applicable codes and ordinances. Warranty is void if wiring is
not in accordance with specifications. Copper wire is required for all power lead
terminations at the unit.
AGZ 010A through AGZ 034A units have single point power connection. A single field
supplied fused disconnect is required. The control transformer is factory mounted.
If the evaporator heater is on a separate disconnect switch from the main unit power supply,
the unit may be shut down without defeating the freeze protection provided by the
evaporator heater.
R-22 data is located on pages 21 through 22, R-407C data in on pages 23 through 24.
R-22
Table 8, Electrical Data Single Point, R-22
Power Supply
Field Wire
Hub (Conduit
Connection)
Field Fuse
or Breaker Size
AGZ
Unit
Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Quantity
Wire
Gauge
75C
Quantity
Nominal
Size
In. (mm)
Recommended
Maximum
208 56 3 6 AWG 1 1.00 (25)
70 70
230 54 3 6 AWG 1 1.00 (25)
60 70
460 26 3 10 AWG
1 1.00 (25)
30 30
010B
575 22 3 10 AWG
1 1.00 (25)
25 25
208 77 3 4 AWG 1 1.00 (25)
90 100
230 77 3 4 AWG 1 1.00 (25)
90 100
460 39 3 8 AWG 1 1.00 (25)
45 50
013B
575 30 3 10 AWG
1 1.00 (25)
35 40
208 82 3 4 AWG 1 1.00 (25)
110 110
230 80 3 4 AWG 1 1.00 (25)
90 100
460 41 3 8 AWG 1 1.00 (25)
50 50
017B
575 33 3 10 AWG
1 1.00 (25)
40 40
208 113 3 2 AWG 1 1.25 (32)
125 150
230 113 3 2 AWG 1 1.25 (32)
125 150
460 50 3 8 AWG 1 1.00 (25)
60 60
020B
575 42 3 8 AWG 1 1.00 (25)
50 50
208 126 3 1 AWG 1 1.25 (32)
150 150
230 126 3 1 AWG 1 1.25 (32)
150 150
460 58 3 6 AWG 1 1.00 (25)
70 70
025B
575 50 3 8 AWG 1 1.00 (25)
60 60
208 138 3 1/0 AWG
1 1.50 (38)
175 175
230 138 3 1/0 AWG
1 1.50 (38)
175 175
460 69 3 4 AWG 1 1.00 (25)
80 90
029B
575 57 3 6 AWG 1 1.00 (25)
70 70
208 182 3 3/0 AWG
1 2.00 (51)
250 250
230 182 3 3/0 AWG
1 2.00 (51)
250 250
460 78 3 4 AWG 1 1.00 (25)
90 100
034B
575 63 3 6 AWG 1 1.00 (25)
70 80
See "Electrical Notes" on page
26
.
